Integrated Interfaces
USB Connections on the Front
The device can be accessed with the DIGSI 5 operating program by plugging a standard USB cable into the
USB-B socket on the front side of the base module. The complete configuration and setting of the device can
be carried out via this connection.
Integrated Interfaces on the Rear Panel of the Device
SIPROTEC 5 Compact provides a permanently installed redundant Ethernet interface on the rear panel. For
this, observe the connection plans in the chapters 3.1.2 Terminals and 3.2.2 Terminals.
Integrated Redundant Ethernet Interface (Port F)
The integrated Ethernet interface is an optical variant (2 x Duplex-LC 1300 nm) and can be configured with or
without integrated switch. It can be used for Ethernet-based protocol applications, for example, IEC 61850,
Modbus TCP, time synchronization via SNTP, network management via SNMP, DIGSI 5 via TCP. Several applica-
tions can run in parallel, whereby unused applications can be switched off for security reasons. The maximum
optically permitted distance via 50/125-µm or 62.5/125-µm multimode optical fibers is 2 km. The optical trans-
mission and receiving level is measured in the module and can be displayed with DIGSI 5.
NOTE
The communication interfaces are not preconfigured. Use DIGSI 5 to carry out the functional adjustment to
the desired protocol application.
4.1
Communication
4.1 Integrated Interfaces
36 SIPROTEC 5 Compact, Hardware Description, Manual
C53000-G5300-C002-3, Edition 12.2021
