Siemens SIPROTEC 5 Compact - Installation and Removal

Connection Elements and Conductor Cross-Sections
i
i
NOTE
Observe the manufacturer specifications when using a bootlace ferrule.
Mechanical Requirements
The fasteners and their associated components are designed for the following mechanical requirements:
Permissible tightening torque at clamping screw 0.7 Nm
Installation and Removal
²
Switch off the device before starting work.
Assembly tool
²
Use a screwdriver (DIN 4 x 0.8).
Removal
²
Use a screwdriver to carefully bend the left and right spring clips outwards.
²
Carefully pull out the terminal block.
²
Seal the contacts with a cover cap (see Figure 5-7 and Figure 5-8).
Installation
²
Pull the cover cap off the terminal.
²
Carefully insert the terminal block into the spring clips.
²
Both spring clips must engage clearly audibly.
5.3.4
Working on the Device
5.3 Installing Current and Voltage Terminals
SIPROTEC 5 Compact, Hardware Description, Manual 51
C53000-G5300-C002-3, Edition 12.2021
