Integrated Ethernet Interface
Integrated Ethernet Interface (Port F)
This terminal is used to load the device with DIGSI 5 using Ethernet. This terminal also enables IEC 61850
Ethernet communication or communication with another protocol via Ethernet, for example, for connecting
an external RTD unit.
Interface Integrated optical Ethernet interface
Connector type 2 x Duplex LC
Wavelength λ = 1300 nm
Baud rate 100 Mbit/s
Protocol DIGSI 5 protocol (secure Web service protocol)
IEC 61850 (MMS and GOOSE)
Modbus TCP
You can switch other network services like SNMP, RSTP, PRP, HSR, SNTP,
and SUP Ethernet on and off.
Max. line length 2 km via 62.5/125-μm multimode optical fiber
Transmitter Power Minimum Typical Maximum
50 μm/125 μm, NA
4
= 0.2
-24.0 dBm -21.0 dBm -17.0 dBm
62.5 μm/125 μm, NA
4
= 0.275
-20.0 dBm -17.0 dBm -14.0 dBm
Receiver sensitivity Maximum -12.0 dBm
Minimum -31.0 dBm
Optical budget
Minimum 7.0 dB for 50 μm/125 μm, NA
4
= 0.2
Minimum 11.0 dB for 62.5 μm/125 μm, NA
4
= 0.275
Interface design Corresponds to IEEE 802.3, 100Base-FX
Laser class 1 as per EN 60825-1/-2 With the use of 62.5 μm/125 μm and 50 μm/125 μm optical fibers
The integrated optical Ethernet interface offers the possibility of replacing the SFPs (Small Form-Factor Plug-
gable) delivered by default for a communication route of up to 2 km by SFPs that can be ordered separately in
order to adapt the interface to different transmission media and longer routes.
6.7
4
Numerical Aperture (NA = sin θ [launch angle])
Technical Data
6.7 Integrated Ethernet Interface
60 SIPROTEC 5 Compact, Hardware Description, Manual
C53000-G5300-C002-3, Edition 12.2021
