Binary Inputs
Binary Input
Standard Binary Input
Rated voltage range DC 24 V to 250 V
Current consumption, picked up Approx. DC 0.6 mA to DC 2.5 mA (independent of the control voltage)
Power consumption, max. 0.6 W
Pickup time Approx. 3 ms
Dropout time
2
Capacitive load (supply-line capaci-
tance)
Dropout time
< 5 nF < 4 ms
< 10 nF < 6 ms
< 50 nF < 10 ms
< 220 nF < 35 ms
Control voltage Adapt the binary-input threshold to be set in the device to the control
voltage.
Range 1 for 24 V, 48 V, and 60 V
Control voltage
V
low
≤ DC 10 V
V
high
≥ DC 19 V
Range 2 for 110 V and 125 V
Control voltage
V
low
≤ DC 44 V
V
high
≥ DC 88 V
Range 3 for 220 V and 250 V
Control voltage
V
low
≤ DC 88 V
V
high
≥ DC 176 V
Maximum admissible voltage DC 300 V
The binary inputs contain interference suppression capacitors. To ensure EMC immunity, use the terminals
shown in the terminal diagrams/connection diagrams to connect the binary inputs to the common potential.
6.3
2
For time-critical applications with low-active signals, consider the specified dropout times. If necessary, provide for active discharge
of the binary input (for example, a resistor in parallel to the binary input or using a change-over contact).
Technical Data
6.3 Binary Inputs
56 SIPROTEC 5 Compact, Hardware Description, Manual
C53000-G5300-C002-3, Edition 12.2021
