Supply Voltage
Power Supply
Power Supply via Integrated Power Supply
Permissible voltage ranges DC 19 V to DC 250 V
AC 92 V to AC 265 V at 50 Hz, 60 Hz
Auxiliary rated voltage V
H
DC 24 V, 48 V, 60 V, 110 V, 220 V
AC 115 V, 230 V at 50 Hz, 60 Hz
Superimposed alternating voltage, peak-to-peak, IEC 60255-11,
IEC 61000-4-17
≤ 15 % of the DC auxiliary rated
voltage (applies to direct voltage
only)
Inrush current ≤ 18 A
Recommended external protection 6 A miniature circuit breaker, charac-
teristic C according to IEC 60898
Internal Fuse
DC 24 V to DC 250 V
AC 115 V to AC 230 V
4 A time-lag, AC 250 V, DC 300 V, UL recognized
SIBA type 179200
Power Consumption (Life Relay Active)
– DC AC 230 V AC 110 V
12 W 42 VA, power factor ≥ 0.25 28 VA, power factor ≥ 0.35
Stored-energy time on outage
or short circuit of the auxiliary
voltage
IEC 61000-4-11
IEC 61000-4-29
In each permissible AC and DC voltage range ≥ 50 ms
6.2
Technical Data
6.2 Supply Voltage
SIPROTEC 5 Compact, Hardware Description, Manual 55
C53000-G5300-C002-3, Edition 12.2021
