Relay Outputs
Relay Outputs
Fast relay (type F)
Making capacity Max. 1000 W (L/R = 40 ms)
Max. 3600 VA (power factor ≥ 0.35, 50 Hz to 60 Hz)
Breaking capacity Max. 30 W (L/R = 40 ms)
Max. 360 VA (power factor ≥ 0.35, 50 Hz to 60 Hz)
AC and DC contact voltage 250 V
Permissible current per contact
(continuous)
5 A
Permissible current per contact
(switching on and holding)
30 A for 1 s (make contact)
Short-time current across closed
contact
250 A for 30 ms
Total permissible current for
contacts connected to common
potential
5 A
Switching time OOT
3
Make time: typical: 4 ms; maximum: 5 ms
Break time: typical: 2 ms; maximum: 5 ms
Rated data of the output contacts
in accordance with UL certification
DC 24 V, 5 A, General Purpose
DC 48 V, 0.8 A, General Purpose
DC 240 V, 0.1 A, General Purpose
AC 120 V, 5 A, General Purpose
AC 250 V, 5 A, General Purpose
AC 250 V, 0.5 hp
B300
R300
Interference suppression capacitors
across the contacts
4.7 nF, ± 20 %, AC 250 V
Monitoring 2-channel activation
6.4
3
OOT (Output Operating Time): Additional delay of the output medium used, for example, 1 ms with electronic relays
Technical Data
6.4 Relay Outputs
SIPROTEC 5 Compact, Hardware Description, Manual 57
C53000-G5300-C002-3, Edition 12.2021
