2.9 Backup Time Overcurrent Protection
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
123
2.9.5 Information List
No. Information Type of In-
formation
Comments
7104 >BLOCK O/C I>> SP >BLOCK Backup OverCurrent I>>
7105 >BLOCK O/C I> SP >BLOCK Backup OverCurrent I>
7106 >BLOCK O/C Ip SP >BLOCK Backup OverCurrent Ip
7107 >BLOCK O/C Ie>> SP >BLOCK Backup OverCurrent Ie>>
7108 >BLOCK O/C Ie> SP >BLOCK Backup OverCurrent Ie>
7109 >BLOCK O/C Iep SP >BLOCK Backup OverCurrent Iep
7110 >O/C InstTRIP SP >Backup OverCurrent InstantaneousTrip
7111 >BLOCK Dir. I> SP >BLOCK direct. Backup OverCurrent I>
7112 >BLOCK Dir. Ip SP >BLOCK direct. Backup OverCurrent Ip
7113 >BLOCK Dir. Ie> SP >BLOCK direct. Backup OverCurrent Ie>
7114 >BLOCK Dir. Iep SP >BLOCK direct. Backup OverCurrent Iep
7130 >BLOCK I-STUB SP >BLOCK I-STUB
7131 >I-STUB ENABLE SP >Enable I-STUB-Bus function
7132 >BLOCK O/CIe>>> SP >BLOCK Backup OverCurrent Ie>>>
7151 O/C OFF OUT Backup O/C is switched OFF
7152 O/C BLOCK OUT Backup O/C is BLOCKED
7153 O/C ACTIVE OUT Backup O/C is ACTIVE
7161 O/C PICKUP OUT Backup O/C PICKED UP
7162 O/C Pickup L1 OUT Backup O/C PICKUP L1
7163 O/C Pickup L2 OUT Backup O/C PICKUP L2
7164 O/C Pickup L3 OUT Backup O/C PICKUP L3
7165 O/C Pickup E OUT Backup O/C PICKUP EARTH
7171 O/C PU only E OUT Backup O/C Pickup - Only EARTH
7172 O/C PU 1p. L1 OUT Backup O/C Pickup - Only L1
7173 O/C Pickup L1E OUT Backup O/C Pickup L1E
7174 O/C PU 1p. L2 OUT Backup O/C Pickup - Only L2
7175 O/C Pickup L2E OUT Backup O/C Pickup L2E
7176 O/C Pickup L12 OUT Backup O/C Pickup L12
7177 O/C Pickup L12E OUT Backup O/C Pickup L12E
7178 O/C PU 1p. L3 OUT Backup O/C Pickup - Only L3
7179 O/C Pickup L3E OUT Backup O/C Pickup L3E
7180 O/C Pickup L31 OUT Backup O/C Pickup L31
7181 O/C Pickup L31E OUT Backup O/C Pickup L31E
7182 O/C Pickup L23 OUT Backup O/C Pickup L23
7183 O/C Pickup L23E OUT Backup O/C Pickup L23E
7184 O/C Pickup L123 OUT Backup O/C Pickup L123
7185 O/C PickupL123E OUT Backup O/C Pickup L123E
7191 O/C PICKUP I>> OUT Backup O/C Pickup I>>
7192 O/C PICKUP I> OUT Backup O/C Pickup I>
7193 O/C PICKUP Ip OUT Backup O/C Pickup Ip
7201 I-STUB PICKUP OUT O/C I-STUB Pickup
7202 O/C PICK. I>Dir OUT Backup O/C Pickup I> directional
7203 O/C PICK. IpDir OUT Backup O/C Pickup Ip directional
7211 O/C TRIP OUT Backup O/C General TRIP command
