2.6 Direct Local Trip
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
91
2.6.3 Settings
2.6.4 Information List
Addr. Parameter Setting Options Default Setting Comments
2201 FCT Direct Trip ON
OFF
OFF Direct Transfer Trip (DTT)
2202 Trip Time DELAY 0.00 .. 30.00 sec; ∞ 0.01 sec Trip Time Delay
No. Information Type of In-
formation
Comments
4403 >BLOCK DTT SP >BLOCK Direct Transfer Trip function
4412 >DTT Trip L1 SP >Direct Transfer Trip INPUT Phase L1
4413 >DTT Trip L2 SP >Direct Transfer Trip INPUT Phase L2
4414 >DTT Trip L3 SP >Direct Transfer Trip INPUT Phase L3
4417 >DTT Trip L123 SP >Direct Transfer Trip INPUT 3ph L123
4421 DTT OFF OUT Direct Transfer Trip is switched OFF
4422 DTT BLOCK OUT Direct Transfer Trip is BLOCKED
4432 DTT TRIP 1p. L1 OUT DTT TRIP command - Only L1
4433 DTT TRIP 1p. L2 OUT DTT TRIP command - Only L2
4434 DTT TRIP 1p. L3 OUT DTT TRIP command - Only L3
4435 DTT TRIP L123 OUT DTT TRIP command L123
