Technical Data
4.6 Transmission of Binary Information (optional)
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
342
4.6 Transmission of Binary Information (optional)
Remote commands
Remote signals
Number of possible remote commands 4
The operating times depend on the communication speed.
The following data require a transmission rate of 512 kBit/s.
The operating times refer to the entire signal path from entry via binary inputs until output of commands via output relays.
Operating times, total approx. minimum 13 ms
typical 17 ms
Dropout times, total approx. typical 24 ms
Number of possible remote signals 24
The operating times depend on the communication speed.
The following data require a transmission rate of 512 kBit/s.
The operating times refer to the entire signal path from entry via binary inputs until output of commands via output relays.
Operating times, total approx. minimum 14 ms
typical 21 ms
Dropout times, total approx. typical 29 ms
