A.4.6 Pre-defined CFC Charts
Device and System Logic
A negator block of the slow logic (PLC1-BEARB) is created from the binary input „>DataStop“ into the internal
single point indication „Unblock DT“.
Figure A-9 Logical Link between Input and Output
