Siemens SIPROTEC 7SD610 User Manual

Appendix
A.10 Measured Values
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
425
A.10 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Lower setting limit for Power Factor (PF<) Set Points(MV) - - - - - CFC CD DD
601 I L1 (IL1 =) Measurement 134 129 No 9 1 CFC CD DD
602 I L2 (IL2 =) Measurement 134 129 No 9 2 CFC CD DD
603 I L3 (IL3 =) Measurement 134 129 No 9 3 CFC CD DD
610 3I0 (zero sequence) (3I0 =) Measurement 134 129 No 9 14 CFC CD DD
612 IY (star point of transformer) (IY =) Measurement - - - - - CFC CD DD
619 I1 (positive sequence) (I1 =) Measurement - - - - - CFC CD DD
620 I2 (negative sequence) (I2 =) Measurement - - - - - CFC CD DD
621 U L1-E (UL1E=) Measurement 134 129 No 9 4 CFC CD DD
622 U L2-E (UL2E=) Measurement 134 129 No 9 5 CFC CD DD
623 U L3-E (UL3E=) Measurement 134 129 No 9 6 CFC CD DD
624 U L12 (UL12=) Measurement 134 129 No 9 10 CFC CD DD
625 U L23 (UL23=) Measurement 134 129 No 9 11 CFC CD DD
626 U L31 (UL31=) Measurement 134 129 No 9 12 CFC CD DD
627 Uen (Uen =) Measurement - - - - - CFC CD DD
631 3U0 (zero sequence) (3U0 =) Measurement - - - - - CFC CD DD
633 Ux (separate VT) (Ux =) Measurement - - - - - CFC CD DD
634 U1 (positive sequence) (U1 =) Measurement - - - - - CFC CD DD
635 U2 (negative sequence) (U2 =) Measurement - - - - - CFC CD DD
641 P (active power) (P =) Measurement 134 129 No 9 7 CFC CD DD
642 Q (reactive power) (Q =) Measurement 134 129 No 9 8 CFC CD DD
643 Power Factor (PF =) Measurement 134 129 No 9 13 CFC CD DD
644 Frequency (Freq=) Measurement 134 129 No 9 9 CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
679 U1co (positive sequence, compounding)
(U1co=)
Measurement - - - - - CFC CD DD
684 U0 (zero sequence) (U0 =) Measurement - - - - - CFC CD DD
801 Temperat. rise for warning and trip (Θ/Θtrip
=)
Measurement - - - - - CFC CD DD
802 Temperature rise for phase L1 (Θ/ΘtripL1=) Measurement - - - - - CFC CD DD
803 Temperature rise for phase L2 (Θ/ΘtripL2=) Measurement - - - - - CFC CD DD
804 Temperature rise for phase L3 (Θ/ΘtripL3=) Measurement - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CFC CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CFC CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CFC CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CFC CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CFC CD DD
7731 PHI IL1L2 (local) (Φ IL1L2=) Measurement - - - - - CFC CD DD
7732 PHI IL2L3 (local) (Φ IL2L3=) Measurement - - - - - CFC CD DD
7733 PHI IL3L1 (local) (Φ IL3L1=) Measurement - - - - - CFC CD DD
7734 PHI UL1L2 (local) (Φ UL1L2=) Measurement - - - - - CFC CD DD
7735 PHI UL2L3 (local) (Φ UL2L3=) Measurement - - - - - CFC CD DD
7736 PHI UL3L1 (local) (Φ UL3L1=) Measurement - - - - - CFC CD DD
7737 PHI UIL1 (local) (Φ UIL1=) Measurement - - - - - CFC CD DD
