Siemens SIPROTEC 7SD610 User Manual

Appendix
A.10 Measured Values
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
426
7738 PHI UIL2 (local) (Φ UIL2=) Measurement - - - - - CFC CD DD
7739 PHI UIL3 (local) (Φ UIL3=) Measurement - - - - - CFC CD DD
7742 IDiffL1(% Operational nominal current)
(IDiffL1=)
IDiff/IRest 134 122 No 9 1 CFC CD DD
7743 IDiffL2(% Operational nominal current)
(IDiffL2=)
IDiff/IRest 134 122 No 9 2 CFC CD DD
7744 IDiffL3(% Operational nominal current)
(IDiffL3=)
IDiff/IRest 134 122 No 9 3 CFC CD DD
7745 IRestL1(% Operational nominal current)
(IRestL1=)
IDiff/IRest 134 122 No 9 4 CFC CD DD
7746 IRestL2(% Operational nominal current)
(IRestL2=)
IDiff/IRest 134 122 No 9 5 CFC CD DD
7747 IRestL3(% Operational nominal current)
(IRestL3=)
IDiff/IRest 134 122 No 9 6 CFC CD DD
7748 Diff3I0 (Differential current 3I0) (Diff3I0=) IDiff/IRest - - - - - CFC CD DD
7751 Prot.Interface 1:Transmission delay (PI1 TD) Statistics 134 122 No 9 7 CFC CD DD
7753 Prot.Interface 1: Availability per min.
(PI1A/m)
Statistics - - - - - CFC CD DD
7754 Prot.Interface 1: Availability per hour (PI1A/h) Statistics 134 122 No 9 8 CFC CD DD
134 121 No 9 3
7761 Relay ID of 1. relay (Relay ID) Measure relay1 - - - - - CFC CD DD
7762 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay1 - - - - - CFC CD DD
7763 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay1 - - - - - CFC CD DD
7764 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay1 - - - - - CFC CD DD
7765 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay1 - - - - - CFC CD DD
7766 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay1 - - - - - CFC CD DD
7767 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay1 - - - - - CFC CD DD
7769 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay1 - - - - - CFC CD DD
7770 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay1 - - - - - CFC CD DD
7771 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay1 - - - - - CFC CD DD
7772 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay1 - - - - - CFC CD DD
7773 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay1 - - - - - CFC CD DD
7774 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay1 - - - - - CFC CD DD
7781 Relay ID of 2. relay (Relay ID) Measure relay2 - - - - - CFC CD DD
7782 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay2 - - - - - CFC CD DD
7783 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay2 - - - - - CFC CD DD
7784 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay2 - - - - - CFC CD DD
7785 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay2 - - - - - CFC CD DD
7786 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay2 - - - - - CFC CD DD
7787 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay2 - - - - - CFC CD DD
7789 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay2 - - - - - CFC CD DD
7790 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay2 - - - - - CFC CD DD
7791 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay2 - - - - - CFC CD DD
7792 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay2 - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
