Siemens SIPROTEC 7SD610 User Manual

Appendix
A.10 Measured Values
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
427
■
7793 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay2 - - - - - CFC CD DD
7794 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay2 - - - - - CFC CD DD
7875 Prot.Interface 1:Transmission delay rec. (PI1
TD R)
Statistics 134 121 No 9 1 CFC CD DD
7876 Prot.Interface 1:Transmission delay send
(PI1 TD S)
Statistics 134 121 No 9 2 CFC CD DD
30654 Idiff REF(% Operational nominal current) (Id-
iffREF=)
IDiff/IRest - - - - - CFC CD DD
30655 Irest REF(% Operational nominal current) (Ir-
estREF=)
IDiff/IRest - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
