Functions
2.10 Automatic Reclosure Function (optional)
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
152
2747 >Pickup L1 AR SP >AR: External pickup L1 for AR start
2748 >Pickup L2 AR SP >AR: External pickup L2 for AR start
2749 >Pickup L3 AR SP >AR: External pickup L3 for AR start
2750 >Pickup 1ph AR SP >AR: External pickup 1phase for AR start
2751 >Pickup 2ph AR SP >AR: External pickup 2phase for AR start
2752 >Pickup 3ph AR SP >AR: External pickup 3phase for AR start
2781 AR off OUT AR: Auto-reclose is switched off
2782 AR on IntSP AR: Auto-reclose is switched on
2783 AR is blocked OUT AR: Auto-reclose is blocked
2784 AR not ready OUT AR: Auto-reclose is not ready
2787 CB not ready OUT AR: Circuit breaker not ready
2788 AR T-CBreadyExp OUT AR: CB ready monitoring window expired
2796 AR on/off BI IntSP AR: Auto-reclose ON/OFF via BI
2801 AR in progress OUT AR: Auto-reclose in progress
2809 AR T-Start Exp OUT AR: Start-signal monitoring time expired
2810 AR TdeadMax Exp OUT AR: Maximum dead time expired
2818 AR evolving Flt OUT AR: Evolving fault recognition
2820 AR Program1pole OUT AR is set to operate after 1p trip only
2821 AR Td. evol.Flt OUT AR dead time after evolving fault
2839 AR Tdead 1pTrip OUT AR dead time after 1pole trip running
2840 AR Tdead 3pTrip OUT AR dead time after 3pole trip running
2841 AR Tdead 1pFlt OUT AR dead time after 1phase fault running
2842 AR Tdead 2pFlt OUT AR dead time after 2phase fault running
2843 AR Tdead 3pFlt OUT AR dead time after 3phase fault running
2844 AR 1stCyc. run. OUT AR 1st cycle running
2845 AR 2ndCyc. run. OUT AR 2nd cycle running
2846 AR 3rdCyc. run. OUT AR 3rd cycle running
2847 AR 4thCyc. run. OUT AR 4th or higher cycle running
2848 AR ADT run. OUT AR cycle is running in ADT mode
2851 AR CLOSE Cmd. OUT AR: Close command
2852 AR Close1.Cyc1p OUT AR: Close command after 1pole, 1st cycle
2853 AR Close1.Cyc3p OUT AR: Close command after 3pole, 1st cycle
2854 AR Close 2.Cyc OUT AR: Close command 2nd cycle (and higher)
2861 AR T-Recl. run. OUT AR: Reclaim time is running
2862 AR successful OUT AR successful
2864 AR 1p Trip Perm OUT AR: 1pole trip permitted by internal AR
2865 AR Sync.Request OUT AR: Synchro-check request
2871 AR TRIP 3pole OUT AR: TRIP command 3pole
2889 AR 1.CycZoneRel OUT AR 1st cycle zone extension release
2890 AR 2.CycZoneRel OUT AR 2nd cycle zone extension release
2891 AR 3.CycZoneRel OUT AR 3rd cycle zone extension release
2892 AR 4.CycZoneRel OUT AR 4th cycle zone extension release
2893 AR Zone Release OUT AR zone extension (general)
2894 AR Remote Close OUT AR Remote close signal send
No. Information Type of In-
formation
Comments
