Siemens SIPROTEC 7SD610 User Manual

Functions
2.17 Additional Functions
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
252
2.17.4.2 Information List
No. Information Type of In-
formation
Comments
601 IL1 = MV I L1
602 IL2 = MV I L2
603 IL3 = MV I L3
610 3I0 = MV 3I0 (zero sequence)
612 IY = MV IY (star point of transformer)
619 I1 = MV I1 (positive sequence)
620 I2 = MV I2 (negative sequence)
621 UL1E= MV U L1-E
622 UL2E= MV U L2-E
623 UL3E= MV U L3-E
624 UL12= MV U L12
625 UL23= MV U L23
626 UL31= MV U L31
627 Uen = MV Uen
631 3U0 = MV 3U0 (zero sequence)
633 Ux = MV Ux (separate VT)
634 U1 = MV U1 (positive sequence)
635 U2 = MV U2 (negative sequence)
641 P = MV P (active power)
642 Q = MV Q (reactive power)
643 PF = MV Power Factor
644 Freq= MV Frequency
645 S = MV S (apparent power)
679 U1co= MV U1co (positive sequence, compounding)
684 U0 = MV U0 (zero sequence)
801 Θ/Θtrip = MV Temperat. rise for warning and trip
802 Θ/ΘtripL1= MV Temperature rise for phase L1
803 Θ/ΘtripL2= MV Temperature rise for phase L2
804 Θ/ΘtripL3= MV Temperature rise for phase L3
7731 Φ IL1L2= MV PHI IL1L2 (local)
7732 Φ IL2L3= MV PHI IL2L3 (local)
7733 Φ IL3L1= MV PHI IL3L1 (local)
7734 Φ UL1L2= MV PHI UL1L2 (local)
7735 Φ UL2L3= MV PHI UL2L3 (local)
7736 Φ UL3L1= MV PHI UL3L1 (local)
7737 Φ UIL1= MV PHI UIL1 (local)
7738 Φ UIL2= MV PHI UIL2 (local)
7739 Φ UIL3= MV PHI UIL3 (local)
