Technical Data
4.1 General
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
325
Binary Outputs
Signalling/Trip Relays (see also terminal assignments in Appendix A.2))
Number and information (allocatable)
UL Listed NO Contact
(normal)
1
)
NO Contact
(fast)
1
)
NO/NC
(switch selectable)
1
)
x5-1
Switching capability MAKE 1000 W/VA
Switching capability OFF 30 VA
40 W ohmic
25 W/VA for L/R ≤ 50ms
Switching voltage
DC 250 V
AC 250 V
Admissible current per contact (continuous) 5 A
Permissible current per contact
(close and hold)
30 A for 0.5 s (NO contact)
Permissible total current
on common path contacts
5 A continuous
30 A for 0.5 s
Permissible relative closing time -
Operating time, approx. 8 ms 5 ms 8 ms
Alarm relay
1
) With 1 NC contact or 1 NO contact (switchable)
Switching capacity MAKE 1000 W/VA
OPEN 30 VA
40 W ohmic
25 VA at L/R ≤ 50 ms
Switching voltage 250 V
Permissible Current per Contact 5 A continuous
30 A for 0.5 s
1
) UL-listed with the following rated data:
AC 120 V Pilot duty, B300
AC 240 V Pilot duty, B300
AC 240 V 5 A General Purpose
DC 24 V 5 A General Purpose
DC 48 V 0.8 A General Purpose
DC 240 V 0.1 A General Purpose
AC 120 V 1/6 hp (4.4 FLA)
AC 240 V 1/2 hp (4.9 FLA)
