Technical Data
4.15 User defined functions (CFC)
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
363
Processing Times in TICKS required by the Individual Elements
Individual Element Number of TICKS
Block, basic requirement 5
Each input more than 3 inputs for generic modules 1
Connection to an input signal 6
Connection to an output signal 7
Additional for each chart 1
Operating sequence module CMD_CHAIN 34
Flipflop D_FF_MEMO 6
Loop module LOOP 8
Decoder DM_DECODE 8
Dynamic OR DYN_OR 6
Addition ADD 26
Subtraction SUB 26
Multiplication MUL 26
Division DIV 54
Square root SQUARE_ROOT 83
Timer TIMER_SHORT 8
Timer LONG_TIMER 11
Blinker lamp BLINK 11
Counter COUNTER 6
Adaptor REAL_TO_DINT 10
Adaptor REAL_TO_UINT 10
Alarm clock ALARM 21
Comparison COMPARE 12
Decoder DIST_DECODE 8
