Page #388 background imageLoading...
Page #388 background image
Appendix
A.7 Settings
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
388
610 FltDisp.LED/LCD Device Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
625A T MIN LED HOLD Device 0 .. 60 min; ∞ 0 min Minimum hold time of lachted
LEDs
640 Start image DD Device image 1
image 2
image 3
image 4
image 5
image 6
image 1 Start image Default Display
1103 FullScaleVolt. P.System Data 2 0.4 .. 1200.0 kV 400.0 kV Measurement: Full Scale Voltage
(100%)
1104 FullScaleCurr. P.System Data 2 10 .. 10000 A 1000 A Measurement: Full Scale Current
(100%)
1105 Line Angle P.System Data 2 10 .. 89 ° 85 ° Line Angle
1106 OPERATION POWER P.System Data 2 0.2 .. 5000.0 MVA 692.8 MVA Operational power of protection
zone
1107 P,Q sign P.System Data 2 not reversed
reversed
not reversed P,Q operational measured values
sign
1111 x' P.System Data 2 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km x' - Line Reactance per length
unit
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
1111 x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi x' - Line Reactance per length
unit
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
1112 c' P.System Data 2 1A 0.000 .. 100.000 µF/km 0.010 µF/km c' - capacit. per unit line len.
µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
1112 c' P.System Data 2 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi c' - capacit. per unit line len.
µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
1113 Line Length P.System Data 2 0.1 .. 1000.0 km 100.0 km Line Length
1113 Line Length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles Line Length
1130A PoleOpenCurrent P.System Data 2 1A 0.05 .. 1.00 A 0.10 A Pole Open Current Threshold
5A 0.25 .. 5.00 A 0.50 A
1131A PoleOpenVoltage P.System Data 2 2 .. 70 V 30 V Pole Open Voltage Threshold
1132A SI Time all Cl. P.System Data 2 0.01 .. 30.00 sec 0.10 sec Seal-in Time after ALL closures
1133A T DELAY SOTF P.System Data 2 0.05 .. 30.00 sec 0.25 sec minimal time for line open before
SOTF
1134 Line Closure P.System Data 2 only with ManCl
I OR U or ManCl
CB OR I or M/C
I or Man.Close
I or Man.Close Recognition of Line Closures
with
1135 Reset Trip CMD P.System Data 2 CurrentOpenPole
Current AND CB
Pickup Reset
CurrentOpenPole RESET of Trip Command
1136 OpenPoleDetect. P.System Data 2 OFF
Current AND CB
w/ measurement
w/ measurement open pole detector
1150A SI Time Man.Cl P.System Data 2 0.01 .. 30.00 sec 0.30 sec Seal-in Time after MANUAL clo-
sures
1151 SYN.MAN.CL P.System Data 2 w/o Sync-check
NO
NO Manual CLOSE COMMAND
generation
1152 Man.Clos. Imp. P.System Data 2 (Setting options depend
on configuration)
None MANUAL Closure Impulse after
CONTROL
1155 3pole coupling P.System Data 2 with PICKUP
with TRIP
with TRIP 3 pole coupling
1156A Trip2phFlt P.System Data 2 3pole
1pole leading Ø
1pole lagging Ø
3pole Trip type with 2phase faults
1161 VECTOR GROUP U P.System Data 2 0 .. 11 0 Vector group numeral for voltage
1162 VECTOR GROUP I P.System Data 2 0 .. 11 0 Vector group numeral for current
1163 TRANS STP IS P.System Data 2 Solid Earthed
Not Earthed
Solid Earthed Transformer starpoint is
1201 STATE OF DIFF. Diff. Prot OFF
ON
ON State of differential protection
Addr. Parameter Function C Setting Options Default Setting Comments
