Siemens SIPROTEC 7SD610 User Manual

Appendix
A.7 Settings
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
392
2933 FAST Σ i SUPERV Measurem.Superv ON
OFF
ON State of fast current summation
supervis
2935A ΔI min Measurem.Superv 1A 0.05 .. 1.00 A 0.10 A Min. current diff. for wire break
det.
5A 0.25 .. 5.00 A 0.50 A
2941 ϕA Measurem.Superv 0 .. 359 ° 200 ° Limit setting PhiA
2942 ϕB Measurem.Superv 0 .. 359 ° 340 ° Limit setting PhiB
2943 I1> Measurem.Superv 1A 0.05 .. 2.00 A 0.05 A Minimum value I1>
5A 0.25 .. 10.00 A 0.25 A
2944 U1> Measurem.Superv 2 .. 70 V 20 V Minimum value U1>
3401 AUTO RECLOSE Auto Reclose OFF
ON
ON Auto-Reclose Function
3402 CB? 1.TRIP Auto Reclose YES
NO
NO CB ready interrogation at 1st trip
3403 T-RECLAIM Auto Reclose 0.50 .. 300.00 sec 3.00 sec Reclaim time after successful AR
cycle
3403 T-RECLAIM Auto Reclose 0.50 .. 300.00 sec; 0 3.00 sec Reclaim time after successful AR
cycle
3404 T-BLOCK MC Auto Reclose 0.50 .. 300.00 sec; 0 1.00 sec AR blocking duration after
manual close
3406 EV. FLT. RECOG. Auto Reclose with PICKUP
with TRIP
with TRIP Evolving fault recognition
3407 EV. FLT. MODE Auto Reclose Stops AutoRecl
starts 3p AR
starts 3p AR Evolving fault (during the dead
time)
3408 T-Start MONITOR Auto Reclose 0.01 .. 300.00 sec 0.50 sec AR start-signal monitoring time
3409 CB TIME OUT Auto Reclose 0.01 .. 300.00 sec 3.00 sec Circuit Breaker (CB) Supervision
Time
3410 T RemoteClose Auto Reclose 0.00 .. 300.00 sec; ∞ 0.20 sec Send delay for remote close
command
3411A T-DEAD EXT. Auto Reclose 0.50 .. 300.00 sec; ∞∞sec Maximum dead time extension
3420 AR WITH DIFF Auto Reclose YES
NO
YES AR with differential protection ?
3421 AR w/ SOTF-O/C Auto Reclose YES
NO
YES AR with switch-onto-fault over-
current ?
3423 AR WITH I.TRIP Auto Reclose YES
NO
YES AR with intertrip ?
3424 AR w/ DTT Auto Reclose YES
NO
YES AR with direct transfer trip ?
3425 AR w/ BackUpO/C Auto Reclose YES
NO
YES AR with back-up overcurrent ?
3430 AR TRIP 3pole Auto Reclose YES
NO
YES 3pole TRIP by AR
3431 DLC / RDT Auto Reclose WITHOUT
DLC
WITHOUT Dead Line Check / Reduced
Dead Time
3433 T-ACTION ADT Auto Reclose 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3434 T-MAX ADT Auto Reclose 0.50 .. 3000.00 sec 5.00 sec Maximum dead time
3435 ADT 1p allowed Auto Reclose YES
NO
NO 1pole TRIP allowed
3436 ADT CB? CLOSE Auto Reclose YES
NO
NO CB ready interrogation before re-
closing
3437 ADT SynRequest Auto Reclose YES
NO
NO Request for synchro-check after
3pole AR
3438 T U-stable Auto Reclose 0.10 .. 30.00 sec 0.10 sec Supervision time for dead/live
voltage
3440 U-live> Auto Reclose 30 .. 90 V 48 V Voltage threshold for live line or
bus
3441 U-dead< Auto Reclose 2 .. 70 V 30 V Voltage threshold for dead line or
bus
3450 1.AR: START Auto Reclose YES
NO
YES Start of AR allowed in this cycle
3451 1.AR: T-ACTION Auto Reclose 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3453 1.AR Tdead 1Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3454 1.AR Tdead 2Flt Auto Reclose 0.01 .. 1800.00 sec; ∞
1.20 sec Dead time after 2phase faults
Addr. Parameter Function C Setting Options Default Setting Comments
