Functions
2.3 Differential Protection
SIPROTEC, 7SD610, Manual
C53000-G1176-C145-6, Release date 02.2011
77
3181 Diff Flt. L12E OUT Diff: Fault detection L12E
3182 Diff Flt. 1p.L3 OUT Diff: Fault detection L3 (only)
3183 Diff Flt. L3E OUT Diff: Fault detection L3E
3184 Diff Flt. L31 OUT Diff: Fault detection L31
3185 Diff Flt. L31E OUT Diff: Fault detection L31E
3186 Diff Flt. L23 OUT Diff: Fault detection L23
3187 Diff Flt. L23E OUT Diff: Fault detection L23E
3188 Diff Flt. L123 OUT Diff: Fault detection L123
3189 Diff Flt. L123E OUT Diff: Fault detection L123E
3190 Test Diff. IntSP Diff: Set Teststate of Diff. protection
3191 Comm. Diff IntSP Diff: Set Commissioning state of Diff.
3192 TestDiff.remote OUT Diff: Remote relay in Teststate
3193 Comm.Diff act. OUT Diff: Commissioning state is active
3197 >Test Diff. ON SP Diff: >Set Teststate of Diff. protection
3198 >Test Diff. OFF SP Diff: >Reset Teststate of Diff. protec.
3199 Test Diff.ONoff IntSP Diff: Teststate of Diff. prot. ON/OFF
3200 TestDiffONoffBI IntSP Diff: Teststate ON/OFF via BI
3260 >Comm. Diff ON SP Diff: >Commissioning state ON
3261 >Comm. Diff OFF SP Diff: >Commissioning state OFF
3262 Comm Diff.ONoff IntSP Diff: Commissioning state ON/OFF
3263 CommDiffONoffBI IntSP Diff: Commissioning state ON/OFF via BI
3525 > Diff block SP >Differential protection blocking signal
3526 Diffblk.rec PI1 OUT Differential blocking received at PI1
3528 Diffblk.sen PI1 OUT Differential blocking sending via PI1
No. Information Type of In-
formation
Comments
To Next Page
