2.16 Backup Time Overcurrent Protection
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
308
For the tripping signals (table 2-13) the stage which caused the tripping is also output. If the device has the
option to trip single-pole, and if this option has been activated, the pole which has been tripped is also indicated
(refer also to Section 2.25.1„Tripping Logic of the Entire Device“).
Table 2-13 Trip signals of the indvidual phases
1)
If tripping by the 3I0 measuring unit is performed simultaneously with or after tripping by a phase measuring
unit and if 1-pole tripping is active, „O/C TRIP 1p.L1“, „O/C TRIP 1p.L2“ or „O/C TRIP 1p.L3“ is signalled.
2)
If tripping is only performed by the 3I0 measuring unit but not by a phase measuring unit, „O/C TRIP L123“
is signalled.
I>>> PU L1
I>>> PU L2
I>>> PU L3
I>>> PU E
2-155
2-155
2-155
2-155
„I-STUB PICKUP“ 7201
(All pickups) „O/C PICKUP“ 7161
Internal indication Display Output indication No.
I>> PU L1
I> PU L1
Ip PU L1
I>>> PU L1
1)
2-153
2-154
2-155
„O/C TRIP 1p.L1“ or „O/C TRIP L123“
7212 or
7215
I>> PU L2
I> PU L2
Ip PU L2
I>>> PU L2
1)
2-153
2-154
2-155
„O/C TRIP 1p.L2“ or „O/C TRIP L123“
7213 or
7215
I>> PU L3
I> PU L3
Ip PU L3
I>>> PU L3
1)
2-153
2-154
2-155
„O/C TRIP 1p.L3“ or „O/C TRIP L123“
7214 or
7215
I>> PU E
I> PU E
Ip PU E
I>>> PU E
2)
2-153
2-154
2-155
„O/C TRIP L123“ 7215
I>> PU L1
I>> PU L2
I>> PU L3
I>> PU E
2-153
2-153
2-153
2-153
„O/C TRIP I>>“ 7221
I> PU L1
I> PU L2
I> PU L3
I> PU E
„O/C TRIP I>“ 7222
Ip PU L1
Ip PU L2
Ip PU L3
Ip PU E
2-154
2-154
2-154
2-154
„O/C TRIP Ip“ 7223
I>>> PU L1
I>>> PU L2
I>>> PU L3
I>>> PU E
2-155
2-155
2-155
2-155
„I-STUB TRIP“ 7235
(PU all) „O/C TRIP“ 7211
Internal Indication Display Output Indication No.
