Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
514
Table 3-11 Jumper setting for contact type of binary output BO13
The set nominal current of the current input transformers are checked on the input/output board C-I/O-2. All
jumpers must be set for one nominal current, i.e. one jumper (X61 to X64) for each input transformer and ad-
ditionally the common jumper X60. But: In the version with sensitive earth fault current input (input transformer
T8) there is no jumper X64.
Jumpers X71, X72 and X73 on the input/output board C-I/O-2 are used to set the bus address and must not be
changed. The following table lists the jumper presettings.
Mounting location:
with housing size
1
/
2
: No. 3 in Figure 3-3, slot 33,
with housing size
1
/
1
: No. 3 in Figure 3-4, slot 33 right.
Table 3-12 Jumper settings of Board Address of the input/output board C-I/O-2
Jumper Open in Quiescent State (NO) Closed in Quiescent State (NC) Factory Setting
X41 1-2 2-3 1-2
Jumper Factory Setting
X71 1-2 (H)
X72 1-2 (H)
X73 2-3 (L)
