Mounting
7.4 Disassembly
SIRIUS 3RA28 function modules for mounting on 3RT2 contactors
Manual, 02/2019, A5E03656507620A/RS-AD/005
51
7.4.2 Function module for star-delta (wye-delta) start
Will Cause Death, Serious Injury or Property Damage
Turn off and lock out all power supplying this device before working on this device.
Use a screwdriver to release the locking mechanisms.
Remove the module connectors from the slot by lifting them up and out.
