Siemens SIRIUS 3RT2 - Replacing the Removable Terminal

Mounting
7.5 Replacing the removable terminal
SIRIUS 3RA28 function modules for mounting on 3RT2 contactors
Manual, 02/2019, A5E03656507620A/RS-AD/005
53
7.5 Replacing the removable terminal
DANGER
Hazardous Voltage
Will Cause Death, Serious Injury or Property Damage
Turn off and lock out all power supplying this device before working on this device.
①
Press the interlock.
②
Remove the terminal.
