SIRIUS 3RA28 function modules for mounting on 3RT2 contactors
Manual, 02/2019, A5E03656507620A/RS-AD/005
77
Dimension drawings
B
B.1 CAx data
You can find the CAx data in the Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/16208/td).
1. Enter the full article number of the desired device in the "Product" field, and confirm with
the Enter key.
2. Click the "CAx data link.
