Application example
The 󹪝gure below shows how to connect the 3UG4983 upstream module to the 3UG4583
insulation monitoring relay.
$

<
<

<
/
96


$
9
9
/
.(
9/  
9/ 
9
/
/
9(
9
9
96
/
/
/
1
3(
8*$
8*&:
Figure 13-21 Connection example: Upstream module - insulation monitoring relay
Note
The maximum cable length between the 3UG4583 insulation monitoring relay and the
3UG4983 upstream module is 0.4 m.
Note
The maximum cable length of the measuring circuit connections is 50 m or 100 pF/m.
13.3.2.2 Technical data
Technical data sheet
You can also 󹪝nd the technical data of the product at Siemens Industry Online Support (
https://
support.industry.siemens.com/cs/ww/en/ps/16367/td).
1. Enter the full article number of the desired device in the "Product" 󹪝eld, and con󹪝rm with the
Enter key.
2. Click the "Technical data" link.
Accessories
13.3 Accessories for 3UG458.-1AW30 / 3UG4583-1CW30 insulation monitoring relays
SIRIUS 3UG4 / 3RR2 monitoring relay
Equipment Manual, 07/2021, NEB927043002000/RS-AD/005 271
