SITRANS P DS III/P410 (7MF4.33.. 7MF4.34.. 7MF4.35..)
4 A5E03434626-04, 05/2015
SITRANS P DS III and SITRANS P410
These instructions describe the pressure transmitters SITRANS P DS III and SITRANS P410. The main difference of the
SITRANS P410 is the higher measuring precision compared to the SITRANS P DS III. Refer to the "Technical specifications"
section in the operating instructions, since the measuring precision is not described in these compact operating instructions.
The SITRANS P410 can be ordered for specific device variants via the order option C41.
This history establishes the correlation between the current documentation and the valid firmware of the device.
The documentation of this edition applies to the following firmware:
Firmware ID (FW) on the nameplate
Installation path for PDM
05/2015 HART: FW: 11.03.03, FW: 11.03.04,
FW: 11.03.05, FW: 11.03.06
SIMATIC PDM
8.x
SITRANS P DSIII HART: SITRANS P
PA: FW: 301.01.10 SITRANS P DSIII PA: SITRANS P DSIII
and SITRANS P DSIII PA 3.01
FF: FW: 11.01.02 SITRANS P410 HART: SITRANS P
SITRANS P410 PA: SITRANS P410 PA
No parameter assignment with PDM
Scope of the instructions
Table 1-1 "7MF4.3.." stands for:
SITRANS P DS III/P410 for
Gauge pressure, flush mounted diaphragm
Absolute pressure from the gauge pressure series
Absolute pressure from the differential pressure series
Differential pressure and flow rate, PN 32/160 (MAWP 464/2320 psi)
7MF453.. Differential pressure and flow rate, PN 420 (MAWP 6092 psi)
Depending on the variant, the pressure transmitter measures corrosive, non-corrosive and hazardous gases, vapors and
liquids.
You can use the pressure transmitter for the following types of measurement:
● Gauge pressure
● Absolute pressure
● Differential pressure
With appropriate parameter settings and the necessary add-on parts (e.g. flow limiters and remote seals), the pressure
transmitter can also be used for the following measurements:
● Level
● Volume
● Mass
