Scale parameters and functions
8.7 DR 6 limit value settings
SIWAREX WP321
Manual, 07/2014, A5E33715669A-02
61
DR 6 limit value settings
The switch-on and switch-off values for the limits are configured in data record DR 6.
● Check all parameters and modify them as required
● Transfer the data record to the scale
Table 8- 4 Assignment of data record 6
Data record
number
Contains no. of data rec-
ord
USHORT 2 r 6 - -
Length Data record length infor-
mation
USHORT 2 r 60 - -
Application Information about which
application the DR be-
longs to
USHORT 2 r 201 - -
Version identi-
fier
Information on the current
data record version
USHORT 2 r 1 1 65 635
DR 6 limit
value settings
(Page 61)
Gross / net basis of limit
values 1 and 2
0: Limit value 1 and limit
value 2 are based on the
gross value
1: Limit value 1 and limit
value 2 are based on the
net value
USHORT 2 rw 0 0 1
Reserve Reserve USHORT 2 rw 0 0 -
Limit value 1
ON (Page 63)
Switch-on point for limit
value 1 (% of measuring
range)
FLOAT 4 rw 0 maxi-
mum
number
range
maxi-
mum
number
range
Reserve Reserve TIME 4 rw 0 0 maxi-
mum
number
range+
Limit value 1
OFF
(Page 63)
Switch-off point for limit
value 1 (% of measuring
range)
FLOAT 4 rw 0 maxi-
mum
number
range
maxi-
mum
number
range
Reserve Reserve TIME 4 rw 0 0 maxi-
mum
number
range+
Limit value 2
ON (Page 63)
Switch-on point for limit
value 2 (% of measuring
range)
FLOAT 4 rw 0 maxi-
mum
number
range
maxi-
mum
number
range
