Scale parameters and functions
8.16 DR 34 ASCII main display value
SIWAREX WP321
82 Manual, 07/2014, A5E33715669A-02
8.16
DR 34 ASCII main display value
The ASCII weight corresponds to the value on the main display of the scales and can be
used for a supplementary display as well as the legal trade main display.
Table 8- 14 Assignment of data record 34
Variable
Note
Type
L
Rw
Default
Min.
Max.
Data record
number
Contains no. of data record USHORT 2 r 34 - -
Length Data record length information USHORT 2 r 26 - -
Application Information about which application
the DR belongs to
USHORT 2 r 201 - -
Version identi-
fier
Information on the current data
record version
USHORT 2 r 1 1 65 635
ASCII display
string header
Maximum length and actual length
of string
UBYTE[2] 2 r 16,2 - -
Content of
main display
as ACII string
(Page 83)
For display of the weight value and
other current values (see below)
CHAR[16] 16 r " " - -
