Scale parameters and functions
8.8 DR 9 module information
SIWAREX WP321
Manual, 07/2014, A5E33715669A-02
65
No entries can be made in data record DR 9. This data record provides information on the
inner workings of the SIWAREX module. This information is used to identify the module at
the manufacturer plant (e.g. in the event of repairs). The entries in the data record are of no
importance to the user for operation.
Table 8- 5 Assignment of data record 9
Data record
number
Contains no. of data record USHORT 2 r 9 - -
Length Data record length information USHORT 2 r 68 - -
Application Information about which appli-
cation the DR belongs to
USHORT 2 r 201 - -
Version identi-
fier
Information on the current data
record version
USHORT 2 r 1 1 65 635
Order number
- header
Maximum and current string
length for the order number
UBYTE[2] 2 r 16,16 - -
Order number Order number of the module
7MH ..
CHAR[16] 16 r "7MH …" - -
Serial number
- header
String header UBYTE[2] 2 r 12,12 - -
Serial number Serial number " XXX00001" CHAR[12] 12 r " " - -
Firmware type
- header
String header UBYTE[2] 2 r 2,2 - -
Firmware type Reference V - Release
B - Test
etc.
CHAR[2] 2 r 'V ' - -
Firmware
version - 1st
position
Version 1. USHORT 2 r 1 - -
Firmware
version - 2nd
position
Version 2. USHORT 2 r 0 - -
Firmware
version - 3rd
position
Version 3. USHORT 2 r 0 - -
Hardware
version num-
ber
ES hardware version number
(e.g. 03)
USHORT 2 r 1 - -
OS version
header
String header UBYTE[2] 2 r 2,2 - -
OS version
(loader) -
designation
Reference V - Release
B - Test
etc.
CHAR[2] 2 r 'V ' - -
OS version
(loader) -
designation
e.g. version n USHORT 2 r 'V ' - -
