Siemens SIWAREX WP321 Manual

Scale parameters and functions
8.14 DR 31 advanced current process values
SIWAREX WP321
Manual, 07/2014, A5E33715669A-02
77
8.14
DR 31 advanced current process values
Current states and process values in the scales can be monitored using advanced process
values and process values (DR 30). This data is not required for standard operation of the
scales.
Monitoring selected data during trial operation is extremely useful as it helps you to optimize
parameters.
Procedure
● Read data record DR 31
● Display/analyze the required tags
Table 8- 12 Assignment of data record 31
Variable
Note
Type
L
Rw
Default
Min.
Max.
Data record
number
Contains no. of data record USHORT 2 r 31 - -
Length Data record length information USHORT 2 r 24 - -
Application Information about which applica-
tion the data record belongs to
USHORT 2 r 201 - -
Version iden-
tifier
Information on the current data
record version
USHORT 2 r 1 1 65 635
Unfiltered
digit value
(Page 77)
Unfiltered digit value of AD con-
verters / digital load cells
LONG 4 r 0 - -
Filtered digit
value
(Page 77)
Filtered digit value of AD convert-
ers / digital load cells after dig.
filter 1
LONG 4 r 0 - -
Reserve 1 SHORT 2 r 0 -100 100
Refresh
counter for
process val-
ues
(Page 78)
Refresh counter incremented by 1
if weight values have been
changed
USHORT 2 r 0 - -
Reserve 2 FLOAT 4 r 0 - -
8.14.1
Unfiltered digit value
The unfiltered digit value is the internal measured value immediately before filtering.
8.14.2
Filtered digit value
The filtered digit value is the internal measured value immediately after filtering.
