Figure 59 - Termination of Armoured Cable to CET bar
6.6.4 Terminate the cable armouring – General Items
If required and when the detector loop tails have been terminated, the connection to the Loop
Detector Termination Board must be made with wires twisted together as pairs.
Cables can be identified as to their destinations and additional cable idents may be required on
specific contracts.
After the site cabling has been terminated, additionally check:
• The cable connections to the SEBs or CET are tight
• The street cables are terminated correctly into the appropriate connectors.
