Siemens ST950 Plus+ - A.11 Other Spares; Controller Fuses

Appendix
ST950 Plus+ User Manual
Page 168 of 176
667/HE/53000/000
Issue 2
Unrestricted
A.11 Other Spares
Description
Part Number
27C Yale Door Lock Kit
667/1/21384/000
Yale Lock Barrel Protector kit
667/1/21498/000
Mains Isolator Locking Kit
667/1/33073/000
Manual Panel Gasket
667/7/27129/000
Sealant strip self adhesive PVC 20mm x 6mm per m
667/4/04026/023
Base sealant - Robnorganic PX212ZF (or similar)
992/4/00216/000
Intelligent Detector Backplane with Control PCB
Assy
667/1/32910/950
Loop Detector Termination Board Assy
667/1/32915/000
IDB Ribbon Cable Assy (IDB to Loop Termination
Board)
667/1/32917/000
CPU Card Power Cableform
667/1/45960/000
RJ45 cable for I/O card 0.2m length
998/4/88351/002
RJ45 cable for I/O card 0.5m length
998/4/88351/005
RJ45 cable for I/O card 1.0m length
998/4/88351/010
RJ45 cable for I/O card 2.0m length
998/4/88351/020
RJ45 cable for I/O card 3.0m length
998/4/88351/030
Manual Panel On/Off Only
667/1/27056/010
48V 480W PSU KIT (includes mains side connector)
667/1/53057/000
24V PSU
605/4/08717/000
HIGH LOAD UPGRADE KIT
667/1/53030/001
REDUNDANCY MODULE – NO CABLE
667/1/53185/000
SLD4 Detector – Basic
667/1/45200/001
SLD4 Detector – Enhanced
667/1/45200/011
Heart of the Controller (SD Card)
421/4/97008/004
Sealant Stool to Case
996/4/22026/100
A.12 Controller Fuses
23
The following table lists the fuses fitted in the controller. Fuses should only be replaced with
ones of similar rating and type.
Description
Part Number
Electricity Company Cut-out – High Load ST950
Plus
+
The Max size of this fuse should not exceed 100A
(without reference to Siemens Poole). Maximum
prospective short circuit current must not exceed
N/A
23
The Plus+ Layout Design tool will evaluate whether the design is ‘standard’ or ‘high load’.
