Master Switch Panel
The Master Switch Unit, which comprises the switch gear and some monitoring elements, for all
the incoming mains and the Power Bank. The Power Bank is comprised of the 48VPSUs and
Redundancy Module(s).
There are two variants of the Master Switch Panel, in order to suit a standard or a Hi-load build
configuration.
Figure 14 : Master Switch Unit – Standard
