The Plus+ Design Layout Tool exposes the features, within KeySignals, such as Traffic Phases and
Detection naming, that is referenced by the controller when defined by IC4.
Figure 10 : Plus
+
Design Layout Configuration and IC4 Configuration
To facilitate the layout design, the Plus
+
Design Layout Tool enforces several design decisions and
checks. For example, calculating the number of CICs, 48V PSUs and redundancy modules required
based on the equipment loading.
