ST950 Plus+ User Manual
Page 28 of 176
667/HE/53000/000
Figure 12 : ST950 Plus
+
Cabinet
Manual Panel
Switch Panel
48V PSU
CIC/CTB Card
I/O Card
On-Street Plus+
Cable
Loop Feeder Cable
SLD4 Detectors
Cards
Manual Panel
Master Switch
Panel
48V PSU
ST950 CPU
CIC/CTB Card
I/O Card
On-Street Plus+
Cable
Loop Feeder Cable
SLD4 Detectors
Cards
Gemini Outstation
Unit
