Pin
Top Row
Bottom Row
1
Output 1 Common
Input 1
2
Connected to Pin 1
Input 2
3
Output 1 Normally Open
Input 3
4
Output 1 Normally Closed
Input 4
5
N.C.
Input 5
6
N.C.
Input 6
7
Output 2 Common
Input 7
8
Connected to Pin 7
Input 8
9
Output 2 Normally Open
Input 9
10
Output 2 Normally Closed
Input 10
11
N.C.
Input 11
12
N.C.
Input 12
13
Output 3 Common
Input 13
14
Connected to Pin 13
Input 14
15
Output 3 Normally Open
Input 15
16
Output 3 Normally Closed
Input 16
17
N.C.
Input 17
18
N.C.
Input 18
19
Output 4 Common
Input 19
20
Connected to Pin 19
Input 20
21
Output 4 Normally Open
Input 21
22
Output 4 Normally Closed
Input 22
23
N.C.
Input 23
24
N.C.
Input 24
25
0V
0V
26
0V
0V
Table 8 - CPU IO Card Connector Pin Out
3.13.1 Parts
ST950 CPU I/O kit 24in 4out - 667/1/46014/000
