4 Configuration and Project Engineering
4.1 Creating the project configuration
SINAMICS G120 as a Speed Axis on the S7-1500
V1.0a, Entry ID: 78788716
Copyright Siemens AG 2013 All rights reserved
No. Action Picture
19.
When using PROFINET:
Show the addresses.
The KTP600 is automatically
assigned the next available IP
address 192.168.0.2.
When using PROFIBUS:
Show the addresses.
The KTP600 is automatically
assigned the next available IP
address 192.168.0.2.
Saving the configuration
20. Save the project
