SINAMICS G120 as a Speed Axis on the S7-1500
V1.0a, Entry ID: 78788716
Copyright Siemens AG 2013 All rights reserved
2 Solution
2.1 Overview
Diagrammatic representation
The diagrammatic representation below shows the most important components of
the solution:
Figure 2-1 Solution with the SINAMICS G120 connected via PROFINET
Figure 2-2 Solution with the SINAMICS G120 connected via PROFIBUS
Advantages
Due to the use of the technological functions of the SIMATIC S7-1500, you no
longer need to generate the control word and encode the setpoint to send them to
the SINAMICS G120.
