en Appliance door
44
4.
To completely loosen the inner panel from the door,
carefully pull the upper section of the inner panel
out of the profile and lift it.
1
5.
Lift out the inner panel and set it down carefully on a
flat surface.
6.
Remove the two intermediate panels and their hold-
ers.
The two intermediate panels are not fastened using
retaining pins; instead, they are held in place using
holders.
7.
To separate the two intermediate panels from each
other, remove the holders.
8.
Clean the door panels with glass cleaner and a soft
cloth.
14.2 Fitting the door panels
1.
Insert the two intermediate panels.
Ensure that the intermediate panel is seated cor-
rectly.
a All holders must lay flat against the outer panel.
a If the Low-E symbol can be read on both intermedi-
ate panels, both of the intermediate panels have
been inserted correctly.
2.
Insert the inner panel.
Insert the inner panel into the profile first. The two
fastening pins must then engage in the holders
provided for them.
3.
Remove the locking pins and close the appliance
door.
Note:Do not throw away the locking pins. Store the
locking pins in a secure location. You always require
the locking pins when you remove the door or door
panels from the appliance. If you do not have any lock-
ing pins, you can order these from customer service.
14.3 Detaching the appliance door
If it is particularly dirty, you can remove the appliance
door to clean it more thoroughly.
1.
Open the appliance door fully.
2.
Use the security pins to lock the left- and right-hand
hinges.
The locking pins must be fully inserted into the
holes in the hinges.
3.
Grip the appliance door on either side with both
hands and close it by approx.30degrees.
Do not close the appliance door fully. The hinges
could become bent and the enamel could be dam-
aged.
4.
Lift the appliance slightly and pull it out completely.
14.4 Attaching the appliance door
WARNING‒Risk of injury!
If the hinges are not secured due to an incomplete
lock, they can snap shut with great force.
▶ If the hinge snaps shut when detaching or attaching
the appliance door, do not reach into the hinge.
▶ Call customer service.
If a door pane or appliance door has not been installed
correctly, this is dangerous.
▶ Make sure that all of the door panes and the appli-
ance door have been correctly fitted before you
switch the appliance back on again.
1.
Grip the appliance door on either side with both
hands.
2.
Slide the hinges into the slots in the appliance.
The notch below the hinges must engage into the
frame of the appliance.
3.
Lower the appliance door downwards.
4.
Remove the locking pins.

Siemens VB578D0S0 Specifications

General

Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Pyrolyze power	10960 W
Number of ovens	1
Total oven power	- W
Microwave cooking	-
Oven thermostat range	50 - 280 °C
Top and bottom heating	Yes
Number of cooking programs	10
Total oven(s) interior capacity	112 L
Maximum temperature (conventional)	280 °C
Current	20 A
Connected load	4200 W
AC input voltage	220 - 240 V
Energy efficiency index (EEI)	81.4
Energy consumption (conventional)	0.83 kWh
Energy consumption (forced convection)	1.4 kWh
Door hinge	down
Cord length	1.15 m
Control type	Rotary, Touch
Display type	LCD
Certification	CE
Door material	Glass
Product color	Black
Control position	Front
Appliance placement	Built-in
Door temperature (max)	40 °C
Effective tray surface area	1830 cm²
Clock type	Electronic
Lamp type	Halogen
Package depth	680 mm
Package width	968 mm
Package height	693 mm

Weight and Dimensions

Depth	570 mm
Width	896 mm
Height	594 mm
Weight	60500 g
Depth with door open	1029 mm
Installation compartment depth	560 mm
Installation compartment width	864 mm
Installation compartment height	604 mm
Interior dimensions (W x D x H)	724 x 417 x 371 mm
Installation compartment width (min)	860 mm
Installation compartment height (min)	600 mm
