Copyright © Sigicom AB 2020 34
6.9.6. USB Mode
In this mode, the files and directories of the SD Memory card can be
accessed.
Note! To set USB mode, Monitoring must be OFF.
1. Connect a USB cable between a PC and the USB connector, see
section 4.7.
2. Press .
3. The microSD memory card should now appear as a removable
drive in the file system of the PC.
4. When finished, command the PC to eject the removable drive.
5. Disconnect the USB connector from the instrument. USB cable
shall never be connected in normal run (= Monitoring)
6.9.7. Firmware upgrade
See section 6.14 for a detailed explanation how to upgrade to the latest
FW version.
6.9.8. Display off
From the main screen, the display can be turned off manually by pressing
followed by . Monitoring will not be stopped by this.
