SIGLENT
SSA3000X User Manual 5
1.3 The Front Panel
Figure 1- 6 The Front Panel
Table 1- 1 Front Panel Description
NO.
Description
NO.
Description
1
User Graphical Interface
2
Menu Control Keys
3
Function Keys
4
Knob
5
Arrow Keys
6
RF Input
7
Numeric Keyboard
8
TG Output
9
Earphone interface
10
USB Host
11
Power Switch
