SSA3000X User Manual 7
Selects the Language\Power on/Preset\Interface\Calibration\
system information\Data&Time\Self Test
Selects the Spec Analyzer\EMI\Reflection Meas
Used to Adjust the Grid Brightness\Display Line
Use to Select the File system
Sets the system to default status
Used to Select the RBW\VBW\Attenuator\Freq Step\Sweep time mode
1.3.2 Front Panel Key Backlight
The on/off state and the color of the backlights of some keys at the front panel indicate the working
state of the spectrum analyzer. The states are as listed below.
1. Power Switch
Flash on and off alternatively, in breathing state: indicate the unit is in stand-by state.
Constant on: indicate the instrument is in normal operating state.
2. Mode
When the EMI or Reflection Meas function is enabled, the backlight of Mode turns on .
When the function is Spec Analyzer, the backlight is turn off.
3. TG
When the TG function is enabled, the backlight of TG turns on and turns off when the function
is disabled.
1.3.3 To Use the Numeric Keyboard
SSA3000X provides a numeric keyboard at the front panel (as shown in the figure below). The
numeric keyboard which supports the Chinese characters, English uppercase/lowercase
characters, numbers and common symbols (including decimal point, #, space and +/-) are mainly
used to edit file or folder name and set parameters (refer to “Parameter Setting”).
