SIGLENT
10 SSA3000X User Manual
For fear of damaging your hearing, please turn the volume down to zero
and gradually turn the volume up after putting on the earphone.
4．TG OUTPUT
The output of the tracking generator can be connected to a receiver through a
cable with an N male connector.
To avoid damage to the tracking generator, the reverse DC voltage cannot
exceed 50 V
5．RF INPUT
To avoid damage to the instrument, for the signal input from the RF input
terminal, the DC voltage component and the maximum continuous power
of the AC (RF) signal component can not exceed 50 V and +30 dBm
respectively.
