SIGLENT
SSA3000X User Manual 13
When the sweep time less than the auto couple time,
the measure result may be inaccuracy, at the same
time appear the “UNCAL”
Current parameter and its value
8:Current active cursor; 9:current cursor frequency
value 11:current cursor amplitude value;
Automatically sets the optimal parameters according to
the characteristics of the signal
USB storage device
identification
The identification is displayed when a USB flash drive
is inserted
Function of the current menu.
Menu items of the current function
Local is local mode，RMT is remote mode
The frequency range of the current sweep channel can
be expressed by the combination of center frequency
and span or the combination of start frequency and
stop frequency
Center or start
frequency
The frequency range of the current sweep channel can
be expressed by the combination of center frequency
or the combination of start frequency
Can set the trace A\B\C\D is Clear Write\Max Hold\Min
Hold\Freeze\Average times\Math
Enable or disable Preamplifier
Sweep mode single or continue
Log power\Power\Voltage power
Free\Video\External trigger
34：Ref offset identification；35：Ref offset value
