SIGLENT
SSA3000X User Manual 33
Display the minimum from multiple sweeps for each point of the trace and update the data if a new
minimum is generated in successive sweeps.
4．View
Holds and displays the amplitude data of the selected trace. The trace data is not updated as the
analyzer sweeps.
5．Bank
Disable the trace display and all measurements of this trace.
2.2.2.3 Average Times
Set the number of averages of the selected trace.
More averages can reduce the noise and the influence of other random signals; thus
highlighting the stable signal characteristics. The larger the number of averages is, the
smoother the trace will be.
Table 2- 13 Average Times
2.2.2.4 Math
Set the computational method of the math trace.
1. Variable X、Y
Variable X、Y can be A, B, C.
2. Const
Set the value of the constant.
Table 2- 14 Const
3. Output Z
The result Z will shown on screen in trace A、B、C as you choose.
4. Calculation Type
Spectrum Analyzer provides the calculation types as shown below:
X-Y+Ref→Z
Y-X+Ref→Z
