SIGLENT
SSA3000X User Manual 41
Analyzer provides earphone jack and the demodulated signal can be output in audio
frequency (AF) mode through the earphone. The frequency and intensity of AF denotes the
frequency and amplitude of the signal respectively.
2.2.8.2 Earphone
Set the status of the earphone. When it is on, the demodulated signal can be heard through the
earphone during the demodulation. By default, it is off.
2.2.8.3 Volume
Set the volume of the earphone.
Table 2- 23 Volume
2.2.8.4 Demod Time
Set the time for the analyzer to complete a signal demodulation after each sweep. If Earphone is
set to “On”, you will hear the demodulated signal through the earphone during the demodulation.
You can use the numeric keys, knob or direction keys to modify this parameter. For more details,
please refer to “Parameter Setting”.
Table 2- 24 Demod time
0 ms ~ 100 ms，step=1 ms；
100 ms ~ 1 s，step =10 ms；
1 s ~ 10 s，step =100 ms；
10 s ~ 100 s，step =1 s；
100 s ~ 1000 s，step =10 s
