66
Option Setting Instruction
Cursor Mode Manual In this menu, set the manual cursor measure.
Type Voltage
Time
Use cursor to measure voltage parameters.
Use cursor to measure time parameters.
Source
CH1、CH2
CH3、CH4
MATH
REFA
REFB
REFC
REFD
Select input signal channel.
Cur A
Select this option，turn the “Universal” knob to
adjust cursor A.
Cur B
Select this option，turn the “Universal” knob to
adjust cursor B.
In this mode, the screen displays two horizontal parallel cursors or vertical
parallel cursors to measure voltage or time. You can move the cursor by turning the
“Universal” knob. Before using cursors, you should make sure that you have set the
signal source as the channel for measuring.
■ Voltage Cursor: Voltage cursors appear as horizontal lines on the display and
measure the vertical parameters.
■ Time Cursor: Time cursors appear as vertical lines on the display and measure the
horizontal parameters.
■ Cursor Moving: Use the “universal” knob to move cursor1 and cursor2 .They
could be moved when the corresponding cursor option are selected, and cursor value
will display on the bottom left and top left of the screen when you move the cursor.
To do manual cursor measurements, follow these steps:
1. Press CURSOR button to enter the cursor function menu.
2. Press the “Cursor Mode” option button to select “Manual”.
3. Press the “Type” option button to select “Voltage” or “Time”.
4. Press the “Source” option button to select CH1/CH2/CH3/CH4,MATH,
REFA/ REFB/ REFC/REFD, according to input signal channel.
5. Select “Cur A”, turn the “Universal” knob to adjust Cursor A.
6. Select “Cur B”, turn the “Universal” knob to adjust cursor B.
