10.1 Graphical Representation of the Rotors
The graphical representation of the rotors shows the maximum and minimum
radii of the accessories used. If necessary, the values must be manually
calculated (see
11.1.1 “RCF”, page 62).
Fig. 10.3: Microhematocrite
rotor
Fig. 10.1: Minimum and
maximum radius of a
swing-out rotor
Fig. 10.2: Minimum and
maximum radius of
an angle rotor
