Sigma 3-16P - Page 58

Version 06/2007, Rev. 1.15 of 16/09/2011 - sb page 58 of 75
Translation of the original operating manual
Part no.
Description Max. speed
(rpm)
Max.
gravitational
field (x g)
17376 Round carrier for 4 round bottom tubes with screw cap
40 - 50 ml, max. Ø 29/34 x 85 - 110 mm, e.g. no. 15051,
15052, (13055 with 13350/13550 only),
1 set = 2 pcs.
17346 Round carrier for 3 culture tubes 50 ml, e.g. no. 15151,
1 set = 2 pcs.
17344 Round carrier for 3 culture tubes 50 ml with skirt or flat
bottom, max. Ø 29.4/36 x 90 - 120 mm, 1 set = 2 pcs.
17385 Round carrier for 1 tube 78 - 85 ml, max. Ø 38/40 x 85 -
115 mm, e.g. no. 13085, 15076, 15080,
1 set = 2 pcs.
17390 Round carrier incl. rubber cushion no. 16051, for 1 round
bottom tube 100 ml, max. Ø 45/50 x 85 - 110 mm,
e.g. no. 15100, 15102, 15103, 15106, 1 set = 2 pcs.
17393 Round carrier for 1 bottle 175 - 250 ml with pointed bottom
angle 60°, max. Ø 61.5 x 120 - 165 mm, e.g. no. 151 74,
15175, Corning tubes, 1 set = 2 pcs.
17395 Round carrier for 1 bottle with flat bottom 125 ml,
max. Ø 51 x 90 - 115 mm, e.g. no. 15125, 1 set = 2 pcs.
17400 Round carrier for 1 bottle with flat bottom 200 ml,
max. Ø 57 x 90 - 115 mm, e.g. no. 15202, 1 set = 2 pcs.
17347 Round carrier for 1 bottle with flat bottom, 250 ml,
max. Ø 61.5 x 90 - 125 mm, e.g. no. 15247, 15249; (13255
with 13350/13550 only), 1 set = 2 pcs.
17401 Round carrier incl. rubber cushion no. 16250 for 1 round
bottom tube 175 - 250 ml, max. Ø 57.5 x 90 - 137 mm with
13350 and 150 mm with 13550, e.g. no. 15201, 15206,
15250, 15251, 15254, 1 set = 2 pcs.
11240 Swing-out rotor for microtiter plates, incl. 1 set buckets no.
13145 and plate holder no. 17977,
radius edge 12.7 cm,
radius max. 11 cm
radius min. 4.6 cm,
max. plate height 64 mm
4 200 2 505
2 169
907
11222 Swing-out rotor for microtiter plates, incl. 1 set carriers no.
13222,
radius edge 12.3 cm,
radius max. 10.5 cm,
radius min. 6.5 cm
max. plate height 56 mm
3 000 1 238
1 057
654
11133 Swing-out rotor, 4 place, for buckets no. 13104, 13130 5 000 4 472
13130 Bucket, suitable for 3 culture tubes 15 ml no. 15115,
sealable with cap no. 17109, 17111, 1 set = 2 pcs.
13104 Round bucket, sealable with caps no. 17109 and 17111,
suitable for round carriers Ø 56.5 no. 17000 - 17101 and
bottles 200 ml no. 15202, max. tube length 110 mm,
1 set = 2 pcs.,
max. radius 15.5 cm, min. radius 4.5 cm
5 000 4 332
